MT 672 H 40
Code: TB 70
4-Stroke
Likely
Key Specifications
Manufacturer
MTU Friedrichshafen GmbH
(Germany)
Displacement
268.8 L (16403.4 ci)
Power Output
5220 kW / 7000 hp 7000 hp / 7097.1 PS
Configuration
H 40 Cylinders
Fuel Type
Diesel
Induction
Turbocharged
Unit Converter
Detailed Specifications
| Manufacturer | MTU Friedrichshafen GmbH (Germany) |
|---|---|
| Stroke Type | 4-stroke |
| Configuration | H 40 Cylinders |
| Displacement | 268,802.5 cc (16403.4 ci) |
| Bore × Stroke | 185.0 mm × 250.0 mm (7.283 in × 9.843 in) |
| Power Output |
5,219.9 kW
(7000 hp /
7097.1 PS)
@ 1,700 RPM |
| Peak Power @ | 1,700 RPM |
| Max Speed (Redline) | 1,720 RPM |
| Fuel System | Inline pump |
| Fuel Type | Diesel |
| Induction | Turbocharged |
| Cooling System | Water |
| Data Quality | Likely |
